Side Tilt Carriage - Rated by the tine carriage hoisting capability, there are actually four sizes of hook type tine carriages. The hook type blade carriages have been standardized.
The carriage bar spacing used for Class 1 is approximately thirteen inches and the Class 1 carriage is rated to carry cargo up to 2000lbs. The Class 2 carriage is rated to hold cargo as much as 5,500lbs with carriage bar spacing of 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing utilized for this capacity is twenty five inches.
The carriages for pin type forks may be different depending on the manufacturer. Pin mounted blades could vary by the amount of offset between the fork eye and the blade. Carriage capacity would be determined by the carriage pin size and by the tine size.
